Basic Specifications
Model NO.SG
CoreShell-type Transformer
Cooling MethodDry-type Transformer
Winding TypeMulti-winding Transformer
CertificationISO9001
UsageSingle-phase, Power, Distribution
FrequencyLow Frequency
Shape of CoreEI
Transport PackageWooden Boxes
OriginChina
HS Code8504210000
Product Description
For many years, high-quality materials and advanced technology have been utilized to produce 1kva-2000kva SG series of three-phase isolation transformers. These products comply with VDE0550, IEC 439, JB5555, and GB5226 international and national standards. SG series three-phase isolation transformers are widely used in AC 50/60HZ environments with input and output voltages not exceeding 1000V. The design covers various requirements including voltage levels, connection groups, tap positions, and winding capacity distribution. Key advantages include fire-proofing, moisture-proofing, safety, reliability, energy-saving, and convenient maintenance.
Key Features
- Interference Elimination: Setting up a new center line-earthing eliminates common-mode interference and other noise from the power network.
- Wiring Versatility: Converts three-wire △ wiring into a four-wire Yo system.
- Harmonic Reduction: Utilizing △/Yo isolating transformers can effectively remove the third harmonic and reduce interference signals.
- Grid Purification: Prevents current distortion of nonlinear loads from affecting the power supply and returning to the grid.
- Independent Neutral Line: Produces a new neutral line so equipment remains independent of the grid's neutral line issues.
Frequently Asked Questions
Q1: What are the primary uses of the SG series isolation transformer?
A: It is widely used in AC 50/60HZ power supply occasions for isolation, voltage transformation, and reducing grid interference.
Q2: How does the transformer handle harmonic interference?
A: By using a △/Yo connection, the transformer can eliminate the third harmonic and significantly reduce high-frequency pulse noise.
Q3: Is this transformer suitable for harsh environments?
A: Yes, the SG series is designed to be fire-proof and moisture-proof, ensuring safe and reliable operation in various industrial settings.
Q4: What cooling method is employed in this model?
A: It utilizes a dry-type cooling method, which makes it easier to maintain and safer for indoor installation compared to oil-filled types.
Q5: Can the input and output voltages be customized?
A: Yes, input, output, voltage levels, and connection groups can be designed and manufactured according to specific user requirements.
Q6: What international standards do these transformers meet?
A: They comply with international standards such as VDE0550 and IEC 439, as well as national standards like GB5226.
