High Voltage Er35 Inverter Power Signal Transformer
| TYPE | MATERIAL | Dimensions (mm) | Ap (cm⁴) | Ae (mm²) | Aw (mm²) | AL (nH/N²) | Le (mm) | Ve (mm³) | Wt (g) | Pt (100kHz) |
|---|---|---|---|---|---|---|---|---|---|---|
| ER9.35 | TP4 | 9.35*2.35*4.6 | 0.0059 | 8.20 | 7.24 | 1270.00 | 13.70 | 111.80 | 0.55 | - |
| ER11.5 | PC44 | 10.83*2.45*4 | 0.0078 | 11.70 | 6.67 | 870.00 | 14.00 | 174.00 | 0.85 | 5.0 |
| ER25.5 | PC40 | 25.5*9.3*7.5 | 0.3557 | 44.80 | 79.40 | 1920.00 | 48.20 | 2160.00 | 11.00 | 87.0 |
| ER35/34 | TP4 | 35*16.8*11.3 | 1.6178 | 107.00 | 151.20 | 3000.00 | 72.80 | 7790.00 | 51.00 | - |
| ER42/20 | PC40 | 42.15*21.2*19.6 | 5.4960 | 240.00 | 229.00 | 5340.00 | 98.60 | 23635.00 | 116.00 | 509.0 |
| ER54/36 | 3C85 | 53.5*18.3*17.95 | 3.1500 | 250.00 | 126.00 | 6100.00 | 91.80 | 23000.00 | 61.00 | - |
Specifications:
Key Features:
Application Scope:
Electronic ballast, compact fluorescent lamps, Television receivers, radio cassette players, PC power supplies, Monitors, audio systems, VCD, DVD, UPS, induction cookers, and noise rejection in electronic transformers.
